Optional components for the listed vehicle configurations only, not a complete installation package or final fitment approval. Select no kit for any other vehicle. Confirm the exact dashboard, original radio, connectors, mounting method, trim, rear clearance and factory equipment before ordering.
CTKFD88: selected Ford Transit V363 2015–2021. CTKFD92: selected Ford Transit Custom V362 2013–2021. Both require the matching dashboard WITHOUT an original factory display. Suitable working hazard/door-lock controls and the correct airbag-indicator/trim arrangement must remain. Assess safe reuse of compatible original parts; replacements are needed only when necessary. Never remove or replace a required airbag warning lamp with a card holder.
CTKFD21: black fascia for the matching square original-radio opening in Ford C-Max 2005–2010, Fiesta 2006–2008, Fusion 2006–2012, Galaxy 2006–2014, Kuga 2008–2012, S-Max 2006–2014 or Transit 2006–2013. Double-DIN installation requires cutting the centre bar of the supplied fascia. This kit requires the matching Quadlock harness WITHOUT a 12V ignition feed and the supported 5000C/6000CD/6006CD original radio. It is not offered for curved original-radio openings.
CTKVW05/CTKVW22: selected Volkswagen Passat B6/B7 2005–2015, Eos 2006–2015, Golf Mk5/Mk6 2005–2013, Jetta 2005–2011, Polo 2009–2014, Scirocco 2008–2014 or Touran 2006–2010. Requires a matching RCD200/300/310/500/510 original radio, Quadlock harness and CT24VW09-shaped dashboard. Choose CTKVW05 only for the matching single-Fakra AM/FM connection, or CTKVW22 only for the matching twin-Fakra AM/FM connection. Check actual plugs and fascia, not model year alone. Later MIB/52-way systems and unlisted vehicles are outside this option.
CTKHD06: right-hand-drive Honda Civic hatchback 2012–2014 with the matching basic, non-amplified, non-navigation factory system only. Not for Honda Connect, left-hand-drive, sedan or unverified dashboards. Includes CT23HD25 black fascia and side brackets, CTSHO006.2 CAN-bus interface, CT27AA71 powered DIN AM/FM antenna adapter and CTMULTILEAD.2 patch lead. The original Bluetooth module is bypassed. Supported phone buttons can control a compatible replacement receiver, but original voice recognition is not retained. Confirm the original radio, antenna connection, Bluetooth bypass connection, secure bracket fit and receiver clearance before approval.
CTKVX37/CTKVX38: right-hand-drive Vauxhall Vivaro B 2014–2018 with the matching non-touchscreen original radio, 20-/32-pin radio connections, Fakra AM/FM connection and three rotary climate controls shown in the fitting guides. Choose CTKVX37 for the matching black CT23VX49 fascia, or CTKVX38 for the matching black/silver CT23VX50 fascia. Each has its own documented side-bracket assembly; check the actual fascia and brackets, not colour alone. Both include the CTSVX007.2 analogue steering-control interface, powered CT27AA14 AM/FM adapter, CTMULTILEAD.2 patch lead and CTVXUSB.2 USB socket adapter. Original USB use depends on compatible receiver connections and testing; phone projection is not promised through the original socket. Original touchscreen/navigation systems, later Vivaro generations and unverified dashboards are outside this option.
These options are limited to standard unamplified audio without an original camera or essential functions requiring an unverified retention interface. DAB aerial or factory-DAB retention is separate where the stereo supports DAB. Kit prices cover components only. Existing stereo installation options remain separate and subject to their stated scope; additional parts, fascia work, coding and other labour are assessed and agreed separately.
